Pradžia/Tikslieji mokslai/Fizika
  •   Raibulių rezervuaras

    Raibulių rezervuaras

    Kodas: 3B Scientific 1017591
    Pasiteirauti apie prekę
    Kaina 88935 € su PVM

    Prekę turime sandėlyje. Užsakius ir apmokėjus šiandien iki 14 val., pristatytume kitą darbo dieną.

    Šiuo metu prekės nėra sandėlyje. Numatomas pristatymo laikas nurodytas žemiau.

    Pateikus užsakymą, susisieksime su Jumis ir informuosime apie tikslų numatomą užsakymo pristatymo laiką.

    Šiuo metu prekės nėra sandėlyje. Numatomas pristatymo laikas nurodytas žemiau.

    Pateikus užsakymą, susisieksime su Jumis ir informuosime apie tikslų numatomą užsakymo pristatymo laiką.

    Į krepšelį
    Gamintojas
    3B Scientific
    Pristatymo laikas
    3-6 savaitės

  • Informacija apie prekę
    Prekės kodas 1017591 [U219101]
    Svoris 9 kg
    Išmatavimai 71 x 42 x 41 cm
    Ženklas 3B Scientific

    Ripple Tank PM02
    Equipment set with ripple tank for demonstrating and investigating properties
    of waves using the example of waves in water. The ripple tank is a shallow tank
    with a glass floor inside an aluminium frame, which can be filled with water.
    The tank can be aligned such that it is horizontal by means of adjustable feet.
    It is possible to generate both circular or straight waves in the tank by means
    of localised oscillations in air pressure and the frequency and amplitude of those
    waves can be set up using a control unit. An external counter can be connected
    to the control unit in order to measure frequency. An LED lighting system illuminates
    the ripple tank from above and takes the form of a stroboscope for which both
    asynchronous and synchronous frequencies can be set. Underneath the tank, there
    is an inclined mirror which projects the waves onto a viewing screen. Includes
    a drawer for storage of accessories and carrying handles for transport. Includes
    12 V AC plug-in power supply.



    Frequency range: 1- 60 Hz, continuously adjustable

    Stroboscope lighting: LED

    Terminals for frequency counter: 4-mm safety sockets

    Power supply: 100 –Ÿ 240 V plug-in power supply

    Dimensions of tank structure: 400 x 300 x 320 mm

    Dimensions of projection screen: 375 x 320 mm



    Contents:

    1 Ripple tank with projection mirror, viewing screen and lighting system

    1 Control unit

    1 Plug-in power supply

    1 Module for generating straight waves

    1 Module for generating circular waves

    1 Module for generating two interfering circular waves

    1 Long hose

    3 Obstructing bodies for reflection and refraction (prism, biconcave lens

    and biconvex lens)

    4 Obstructing bodies for setting up a single slit and a double slit

    1 Drainage hose
